Fashionable mirror wireless charger for fast charging

Model:

Name：Mirror Wireless Charge

Features：

1, the input current: DC 1.5 ~ 2A

2, the input voltage: DC5.0V ~ 5.5V, beyond this range voltage alarm and stop charging

3, the output voltage: 5V ± 0.1V,

4, the output current: 1A

5, charging power: 5W

6, conversion efficiency: more than 73%

7, transmission distance: the maximum 5mm, the recommended transmission and receiving spacing 2mm ~ 4mm

8, standby power consumption: the average power consumption is less than 30mW

9, over-current protection: when charging the output current is greater than 2A automatically stop charging to prevent damage to the charger

10, standard: Qi wireless charging standard (WPC1.1)

11, whether to support foreign body detection: support

12, the working frequency: 100KHZ-205KHZ
